7*2W 4in1 RGBW LED Zoom Stage Par Light

5 0 Reviews

AH054A is an aluminum body par light, with 7 * 20 W 4 in 1 RGBW, Quad LED

AH054A with magnet atomizer, various angles are optional

AH054A supports DMX, RDM (remote device management), Art-Net protocol (optional), built-in wireless solution wireless system (optional).

The application of AH054A is not limited. It can be placed in any outdoor/indoor environment, such as wedding scene, stage performance, etc.

Availability:


Inquire

Model: AH054A
Brand: ATON

FEATURES
SPECIFICATIONS
PHOTOMETRIC DATA
ACCESSORIES
DOWNLOAD

3 (2) IMG_1703 (6000x4000) IMG_1707 (6000x4000) IMG_1716 (6000x4000)

AH054A Zoom Kid

Led	7 * 2 W 4 in 1 RGBW, Quad LED	DMX Input/ Output	Seetronic XLR 3 pin or Seetronic XLR 5 pin male and female
Beam aperture	25°	Power Input/Output	Seetronic powerrcon true one in and out
Optical lens	42mm PMMA secondary optics and lens tube	Cabinet Colour	Coat sand painting,Black-RAL9004
Efficiency	95% Optic efficiency	Type	Outdoor
Rated Source life	up to 50,000 hours	Material	Magnesuim aluminium body
Lux	27700 lux@2m 8°；1380 lux@2m 50°	Locking	Key lock for buttons
Electronic	4 selectable Dim Curves (Linear, Square Inv. Squa, S-Curve)	Waterproof	IP65
Voltage	100V - 270V , 50/60Hz	Temperature	-30℃~45℃
Power	150 W	Dimensions	250 x 189 x 339 mm
Displayer	68 built-in Color Macros	N.W	6.1 KG
Cooling	Preset Color Temperatures (2500K-6500K)	G.W	6.8 KG
DMX channel	2,4,8,17 & 19CH	Supports RDM (Remote Devise Management)

Led	7 * 2 W 4 in 1 RGBW, Quad LED	DMX Input/ Output	Seetronic XLR 3 pin or Seetronic XLR 5 pin male and female
Beam aperture	25°	Power Input/Output	Seetronic powerrcon true one in and out
Optical lens	42mm PMMA secondary optics and lens tube	Cabinet Colour	Coat sand painting,Black-RAL9004
Efficiency	95% Optic efficiency	Type	Outdoor
Rated Source life	up to 50,000 hours	Material	Magnesuim aluminium body
Lux	27700 lux@2m 8°；1380 lux@2m 50°	Locking	Key lock for buttons
Electronic	4 selectable Dim Curves (Linear, Square Inv. Squa, S-Curve)	Waterproof	IP65
Voltage	100V - 270V , 50/60Hz	Temperature	-30℃~45℃
Power	150 W	Dimensions	250 x 189 x 339 mm
Displayer	68 built-in Color Macros	N.W	6.1 KG
Cooling	Preset Color Temperatures (2500K-6500K)	G.W	6.8 KG
DMX channel	2,4,8,17 & 19CH	Supports RDM (Remote Devise Management)

7*2W 4in1 RGBW LED Zoom Stage Par Light
