AB09
ATON
| Availability: | |
|---|---|
| LED expected lifetime | 50000H | ||
| Lightsource | 4x20W RGBL | ||
| Type of optical system | PMMA | ||
| LED PWM Frequency | 600-25000HZ | ||
| Native lens options | 10° | ||
| Beam angles | 12° | ||
| Maximum Field angles | 19° | ||
| Color temperature range | 2500-10000K | ||
| CRI/Ra | 90 | ||
| Effi cancy (max) | 45W/lm | ||
| Battery working time @ full light | 4H,6H,8H,10H | ||
| Battery working time @ auto | 8H,12H,16H,20H | ||
| Battery charging time | 6H | ||
| Battery life | 1000 times of charging and discharging | ||
| AC Input | Yes | ||
| Cooling | Natural Cooling | ||
| Humidity (max.) | 96% | ||
| Temperature range, Operating | -40°C~45°C | ||
| AC Power, max | 100 - 260V 50/60Hz | ||
| AC Power, nominal | 100 – 240V 50/60Hz | ||
| Max power consumption | 60W | ||
| Constant power consumption | 60W | ||
| Power Factor | 0.97 | ||
| Power Supply Unit | Inbuilt auto-ranging electronic switch-mode | ||
| DMX channels | 2/3/4/11/16 | ||
| DMX modes | 5CH | ||
| Settng and addressing | TFT display / 4 controls RDM ANSI E1.20 | ||
| Standalone mode | Auto program | ||
| Wireless DMX | Standard Chinese wireless,CRMX(Optional choose) | ||
| Remote | Vision APP by Bluetooth control | ||
| Strobe | 0-20HZ | ||
| IP class | IP65 | ||
| IK class | IK07 | ||
| Lens material | PMMA | ||
| Dimensions | 130*130*120mm | ||
| Net weight | 7KG | ||
| Tilt | 0-220° |
| LED expected lifetime | 50000H | ||
| Lightsource | 4x20W RGBL | ||
| Type of optical system | PMMA | ||
| LED PWM Frequency | 600-25000HZ | ||
| Native lens options | 10° | ||
| Beam angles | 12° | ||
| Maximum Field angles | 19° | ||
| Color temperature range | 2500-10000K | ||
| CRI/Ra | 90 | ||
| Effi cancy (max) | 45W/lm | ||
| Battery working time @ full light | 4H,6H,8H,10H | ||
| Battery working time @ auto | 8H,12H,16H,20H | ||
| Battery charging time | 6H | ||
| Battery life | 1000 times of charging and discharging | ||
| AC Input | Yes | ||
| Cooling | Natural Cooling | ||
| Humidity (max.) | 96% | ||
| Temperature range, Operating | -40°C~45°C | ||
| AC Power, max | 100 - 260V 50/60Hz | ||
| AC Power, nominal | 100 – 240V 50/60Hz | ||
| Max power consumption | 60W | ||
| Constant power consumption | 60W | ||
| Power Factor | 0.97 | ||
| Power Supply Unit | Inbuilt auto-ranging electronic switch-mode | ||
| DMX channels | 2/3/4/11/16 | ||
| DMX modes | 5CH | ||
| Settng and addressing | TFT display / 4 controls RDM ANSI E1.20 | ||
| Standalone mode | Auto program | ||
| Wireless DMX | Standard Chinese wireless,CRMX(Optional choose) | ||
| Remote | Vision APP by Bluetooth control | ||
| Strobe | 0-20HZ | ||
| IP class | IP65 | ||
| IK class | IK07 | ||
| Lens material | PMMA | ||
| Dimensions | 130*130*120mm | ||
| Net weight | 7KG | ||
| Tilt | 0-220° |
ACCESSORIES
![]()
ACCESSORIES
Power cord
European double head
ACCESSORIES
adapter
AC:110V-240V
ACCESSORIES/CONTROLLERS
WIRELESS DMX TRX
Wireless transmission box
ACCESSORIES
Light blocking plate
ACCESSORIES
Spherical atomization cover
ACCESSORIES
Cylindrical atomization hood
ACCESSORIES
![]()
ACCESSORIES
Power cord
European double head
ACCESSORIES
adapter
AC:110V-240V
ACCESSORIES/CONTROLLERS
WIRELESS DMX TRX
Wireless transmission box
ACCESSORIES
Light blocking plate
ACCESSORIES
Spherical atomization cover
ACCESSORIES
Cylindrical atomization hood
