ATON LIGHT CO.Ltd is a high-tech enterprise integrating develop, production and sales. Our main product is stage lights,Wash Lights,Effect lights,Moving Heads, Battery light, LED projection light and light controller and so on. Until now the factory has obtained the ISO 9001 quality management system certification. And all products have passed the certification of CE & ROHS issued by a TUV or an authoritative Laboratory.
ATON LIGHT CO.Ltd is a high-tech enterprise integrating develop, production and sales. Our main product is stage lights,Wash Lights,Effect lights,Moving Heads, Battery light, LED projection light and light controller and so on. Until now the factory has obtained the ISO 9001 quality management system certification. And all products have passed the certification of CE & ROHS issued by a TUV or an authoritative Laboratory.
LED Color | White | Color Temperature | 6500K |
CRI | 80 | DMX channels | 3, 7, 11, 32, & 36 CH |
Quantity of white LED | 96*1W | Quantity of tri LED | 384*0.5W |
Dimming frequency | 600/1200/2400/4800/9600/18000HZ | Dimmer resoluiton | 16bit |
Beam angle | 90° | Output @1M | 9000 lux |
Output @5M | 600lux | Cooling type | Passive cooling |
Strobe speed | 0 – 20Hz | DMX Channel | 3/9/22/36/50/92CH |
Control | 5 pin XLR input/output ‘ | Cabled DMX | RDM & DMX 512 |
Voltage | 100-240VAC, 50/60Hz | Total Power | 140W |
Power Supply Unit | Auto-ranging electronic switch-mode | Color opitons | Black sand coat painting |
Cooling | Active, Forced Air, Temperature-regulated | Temperature Range | -40°C to 50°C |
Display and Seting | TFT display / 4 butions | Waterproof | IP65 |
Lens material | PE and tempered glass front | Material | Aluminium |
Dimensions | 1000 x 90 x 113 mm | Net weight | 4kg |
LED Color | White | Color Temperature | 6500K |
CRI | 80 | DMX channels | 3, 7, 11, 32, & 36 CH |
Quantity of white LED | 96*1W | Quantity of tri LED | 384*0.5W |
Dimming frequency | 600/1200/2400/4800/9600/18000HZ | Dimmer resoluiton | 16bit |
Beam angle | 90° | Output @1M | 9000 lux |
Output @5M | 600lux | Cooling type | Passive cooling |
Strobe speed | 0 – 20Hz | DMX Channel | 3/9/22/36/50/92CH |
Control | 5 pin XLR input/output ‘ | Cabled DMX | RDM & DMX 512 |
Voltage | 100-240VAC, 50/60Hz | Total Power | 140W |
Power Supply Unit | Auto-ranging electronic switch-mode | Color opitons | Black sand coat painting |
Cooling | Active, Forced Air, Temperature-regulated | Temperature Range | -40°C to 50°C |
Display and Seting | TFT display / 4 butions | Waterproof | IP65 |
Lens material | PE and tempered glass front | Material | Aluminium |
Dimensions | 1000 x 90 x 113 mm | Net weight | 4kg |
STANDARD ACCESSORIES
Power Cord
STANDARD
QTY: 1PCS
Dmx Cable
STANDARD
QTY: 1PCS
Waterproof Cover
STANDARD
QTY: 1PCS
OPTIONAL ACCESSORIES
Flight Case
OPTIONAL
QTY: 1PCS
Clamps
OPTIONAL
QTY: 1PCS
Signal Extension Cord
OPTIONAL
QTY: 1PCS
Power Extension Cable
OPTIONAL
QTY: 1PCS
1/4 Turn Fast Lock
OPTIONAL
QTY: 1PCS
Safety Wire
OPTIONAL
QTY: 1PCS
STANDARD ACCESSORIES
Power Cord
STANDARD
QTY: 1PCS
Dmx Cable
STANDARD
QTY: 1PCS
Waterproof Cover
STANDARD
QTY: 1PCS
OPTIONAL ACCESSORIES
Flight Case
OPTIONAL
QTY: 1PCS
Clamps
OPTIONAL
QTY: 1PCS
Signal Extension Cord
OPTIONAL
QTY: 1PCS
Power Extension Cable
OPTIONAL
QTY: 1PCS
1/4 Turn Fast Lock
OPTIONAL
QTY: 1PCS
Safety Wire
OPTIONAL
QTY: 1PCS
