lighting effects. The unique combination of red, amber and warm white colors allows for diverse color mixing and creates various atmospheres. Its blinder function can produce rapid and rhythmic flashes, perfect for stage concerts, parties and other events. Built - in DMX control ensures easy operation and precise lightshow programming. Durable and reliable, this versatile light is a great choice for stage lighting.
AH033
ATON
| LED expected lifetime | 50000H |
| 16-bit control | Yes |
| Lightsource | Main Led Panel: 2×300W + Red + Amber + WW |
| Cabled DMX | 3 pin |
| Color Temperature (White) | 2880K |
| DMX channels | 1/2/4/5/8/10/13/P8/P16/P32/P34/P40/P42 |
| CRI | 81 |
| DMX modes | 13 |
| Efficacy | 1532.18lm/W |
| Protocol | USITT DMX512A, RDM ANSI E1.20 |
| Light output all LEDs on (Main + Auxiliary) | 39094 LM |
| Setting and addressing | Manual settings at the display buttons / RDM |
| Light output all LEDs on (Auxiliary) | 30016 LM |
| DMX data in/out | Seetronic-3PIN waterproof DMX output (K3F2C-W-B) / input (J3F2C-W-B) |
| Lux @ 2m (Main + Auxiliary) | 11844 LX |
| Power Connection | Seetronic-waterproof Power input (SAC3MPX-LY) / output (SAC3FPX-LY) |
| Lux @ 5m (Main + Auxiliary) | 1895 LX |
| Power Input/Output Connector | Seetronic-Waterproof Power Supply Output Black-SAC3FX |
| Lux @ 8m (Main + Auxiliary) | 740 LX |
| Cable Length (power) | European single head waterproof power cable (H0R07), 1.5m×2.5mm² 26mm outer skin, 5mm half-skinned with three-colour thread. |
| Lux @ 10m (Main + Auxiliary) | 474 LX |
| Native beam angle(s) | 50° |
| Cable Length (DMX) | 3PIN waterproof DMX cable, L=65CM, both ends half peeled 2CM |
| Initial field of view (spot angle) | 93° |
| Max output power | Input: 9A@220VAC, Output: 2A@12V / 14A@48V |
| Color options | Fine sand black (Black-RAL 9004) |
| IK rating | IK07 |
| Mounting point | 3 mounting points for fast locks available |
| IP class | IP65 |
| Orientation | Arbitrarily |
| Material | Aluminum magnesium alloy |
| Rigging possibilities | Hanging, wall or floor |
| Net dimensions | 495×299×199mm |
| Safety features | 2 safety wire connection points |
| Net weight | 9.51kg |
| Cooling | Chassis Cooling Fan cooling Copper Tube Heat Sink Cooling |
| Color calibration | 127-255 |
| Humidity (max.) | ≤95% |
| Dimmer curve | Linear / Square Law / Inverse Square Law / S-Curve |
| Temperature range | 0℃-40℃ |
| Dimming | 0-255% |
| Max power consumption | 700W |
| Emulation mode / effect | Yes |
| Constant power consumption | 285W |
| Filters | Magnetic |
| Power factor | 0.96 (220V) |
| LED panel | Main Led Panel: 2×300W + Red + Amber + WW, Auxiliary Led Panel: 32 segments |
| Power Supply Unit | (O.L.P)/(SHORT)/(O.V.P)/(O.T.P)/Input over-under protection |
| Standby power consumption | 16W |
| Maximum Connections | 4 pcs @220V |
| Tilt | Head 40° Whole light 360° |
| Electrical protection | (O.L.P)/(SHORT)/(O.V.P)/(O.T.P)/Input over-under protection |
| Main Led Panel segments | 2 segments |
| Input voltage, absolute max. Rating | 100~240VAC 50~60Hz |
| Screen Type | LCD Touch Screen |
| Max inrush current 230V AC | Cold start 60A/230VAC |
| LED PWM Frequency | 1KHz ~ 18KHz |
| Total power | 700W |
