| Light Source | 24pcs*4W high brightness RGB+CW LED | LED lamp | super compact led shape,35mm*35mm,4 in 1 LED |
| Beam Angle | 60*10 degree | Base Illuminance | 1870 lux at 2m distance |
| Control Protocol | DMX 512 | Control Channels | 1ch,4ch,8ch |
| Power supply | AC 100-250V / 50-60Hz | Power consumption | 0.37A @ 230V/57W max 0.71A @ 120V/58W max |
| Connections | Power input and output,signal input and output | Input voltage | DC 24V |
| Electrical class | I | Tempered glasses | 4 mm |
| Housing Material | Extruded aluminum body, Die-cast aluminium cover | Housing color | Black or silver powder coated |
| Dimensions | 1000 X 53 X 81 mm | Weight | 2.9 kg |
| Operating temperature | -20°C to 40°C | Ingress Protection Rating | IP66 |
