Input protocols: | DMX 512 and RDM ANSI E1.20 (2) | Number of DMX channels | 512 channels |
DMX Structure | 1 universes per device | DMX latency | < 5 ms |
Max.Universes in coexistence | 32 | W-DMX G3 & G4S compatibility: | 2.4 GHz,5.2 & 5.8 GHz (1) |
Standard range: | Up to 700 meters (line of sight) | Normal Power Mode 2.4 GHz: | 100mW |
| Maximum Power Mode 2.4 GHz: | Up to 450mW | DMX Connectors: | 3 pin input and output |
| DC Input: | 2-pole DC 12V 2A power supply | Supplied Accessories: | 3dBi, white, omi-directional antenna and phoenix connector |
| Charge time: | 2.5H | Dischage time: | 88H @TX,440H@RX |
| Net Weight: | 1.2KG | Packed Dimensions:
| W x D x H: 245 x 160 x 45 mm |
