The THUNDER FOUR 4*300W LED Blinder Light is a professional stage lighting solution. With red, amber, and warm white colors, it delivers intense brightness andeven light distribution. Ideal for concerts, theaters, and events, it offers high - quality illumination and reliable performance, meeting various stage lighting needs.
AH034
ATON
| LED Expected Lifetime | 50000H |
| Lightsource | Main Led(4*300W Red+Amber+WW) |
| Type of Optical System | Fresnel lens, reflector |
| Color Temperature (at full) | 2860K |
| CRI | 85 |
| LED PWM | 1KHz ~ 18KHz |
| AC Input | Efficacy:112lm/w |
| Light Output (all LEDs on) | 80038 LM |
| Light Output (warm white) | 73681 LM |
| Light Output (red) | 1513 LM |
| Light Output (amber) | 5530 LM |
| Lux @ 2m | 23688 lx |
| Lux @ 5m | 3790 lx |
| Lux @ 8m | 1480 lx |
| Lux @ 10m | 928 lx |
| Native Beam Angle(s) | 50° |
| Initial Field of View (spot angle) | 93° |
| Color Options | Black-RAL 9004 |
| IK Rating | IK07 |
| IP Class | IP65 |
| Material | Aluminium |
| Net Dimensions | 495*499*203mm |
| Net Weight | 17.87kg |
| Color Calibration | 127-255 |
| Dimming Curve | Linear / Square Law /Inverse Square Law / S-Curve |
| Dimmer | 0-255 |
| Emulation Mode / Effect | Yes |
| LED Panel | Main Led(4*300W Red+Amber+WW) |
| Strobe | 0-20Hz |
| Tilt | Light head 40° whole light 360° |
| Screen Reversal Function | The screen can be reversed |
| Segment Control | 36 segments |
| Indicator | LCD |
| Electrical Protection | V1:43~48V/(O.T.P):N2>110±10℃ |
| Input Over/Under Protection | >=75VAC |
| Input Voltage (absolute max. Rating) | 100~240VAC 47~63Hz |
| Input Voltage (nominal) | 100 - 240V 50/60Hz |
| AC Power Max | 1400W |
| AC Power Nominal | 800W |
| Total Power | 1400W |
| Max Power Consumption | 1400W |
| Constant Power Consumption | 800W |
| Power Factor | 0.96（@230V） |
| Power Max.Out | 1400W |
| Standby Power Consumption | 25W |
| Maximum Connections | 2 pcs @220V |
| 16-bit Control | Cabled DMX:3 pin |
| DMX Channels | 1/4/4D/7/10/13/18/P8/P16/P32/P64/P68/P74/P77 |
| DMX Modes | 14 |
| Protocol | USITT DMX512A,RDM ANSI E1.20 |
| Setting and Addressing | Manual settings at the display buttons/RDM |
| Controls | Touchscreen button |
| USB Firmware Update | External Bluetooth module/wireless DMX |
| DMX Data In/Out | Seetronic-3PIN waterproof DMX output(K3F2C-W-B)/input(J3F2C-W-B) |
| Power Connection | Seetronic-waterproof Power input(SAC3MPX-LY)/output(SAC3FPX) |
| Power Input/Output Connector | Seetronic-Waterproof Power Supply Output Black-SAC3FX |
| Cable Length (power) | European single head waterproof power cable（H0R07)1.5m*2.5mm² |
| Cable Length (DMX) | 3 pin waterproof DMX cable,L=65CM |
| Max Output Power | Input:6A@220VAC/Output:4A@12V / 20A@48V |
