Battery Powered Wireless Color Tube LED Engine 320x0.5W RGB+Mint+Amber Battery Pixel Light

5 0 Reviews

The AB01 Mini Color Tube contains 5 LED chips (red, green, blue, mint and amber) that provide a wide color spectrum and larger color gamut. Its IP65 rating allows it to be used indoors and outdoors in any way. The built-in battery is powerful, and it can be set for a specific length of time to ensure your light gets maximum brightness without draining the battery. It lasts up to 2 hours when displaying white light at maximum brightness.5 The chip LED engine delivers excellent color rendering of 96-98 Ra. In addition, it has four selectable dimming curves to meet your needs in different scenarios and present the best visual effect. There are also a variety of splicing options to choose from, making your installation more flexible and versatile. What's more, this lamp also has a built-in battery and supports wireless and 2.4G remote control, making it more convenient for you to use it without having to worry about power or complicated wiring.

Model:
AB01A
Brand:
ATON

Availability:



Inquire

Parameter List

LED expected lifetime	50000H
Lightsource	64 * 0.5W R + 64 * 0.5W G + 64 * 0.5W B + 64 * 0.5W M + 64 * 0.5W A
Battery working time @ full light	4H
Battery working time @ auto	8H
Battery charging time	4H
Color calibration	0-255
Dimming curve	Linear / Square Law 1 / Square Law 2 / Square Law 3
Dimmer	0-255%
Strobe	0-20Hz adjustable
Segment control	16 segments
Screen Type	LCD
Efficacy	12 lm/W
Light output all LEDs on	572 lm
Light output blue	70 lm
Light output green	358 lm
Light output red	70 lm
Light output Mint	172 lm
Light output Amber	402 lm
Lux @ 2m	48 lx
Lux @ 5m	8 lx
Lux @ 8m	3 lx
Lux @ 10m	2 lx
Native beam angle(s)	115° (No lens)
Initial field of view (spot angle)	158°
Input voltage, absolute max. Rating	90 - 264VAC / 47-63HZ
Input voltage, nominal	100V - 240VAC 50/60Hz
Max inrush current 240V AC	30A
Max power consumption	70 W
Constant power consumption	50 W
Standby power consumption	0.3 W
Total power	70W
DMX channels	2/HSV/5/10/12/20/40/80/85CH
Protocol	USITT DMX512 / CRMX / WI DMX
Color options	Black-RAL 9004 / White
IP class	IP65
Material	Aluminium / PC
Net dimensions	10604444mm
Net weight	1.19kg
